Cost Equipment Pyrolysis Plant For Plastic Waste Pyrolysis Waste
Cable Plant
1. The waste plastic pyrolysis plant function is converting waste
plastic into fuel oil, carbon black, and syngas.
2. Capacity from 1 ton-15ton capacity per batch. Support
customization.
3. Fast installation design & Bulk type design &Container
design.
4. Environmental friendly, no black smoke and waste water
discharged out.
5. Large condensing area ensures a high oil yield.
6. Low operating cost.
7. High Automation. Auto feeding systems and discharging carbon
black devices make this recycling machinery much easier to operate.
8. Certification: CE, ISO, SGS, BV.
9. Material of reactor: Q345R/Q245R/310S+Boiler plate/Stainless
steel, thickness 16mm/18mm.
Oil yield of different kinds of plastic
| Raw materials | Oil ratio |
| PP (Microwave oven food box/yogurt bottles, ect.) | 50%-75% |
| PS(fast food boxes/instant noodle boxes) | 50%-75% |
| PE(plastic film/plastic wrap) | 50%-75% |
| Plastic cable | 80% |
| ABS(engineering plastic) | 40% |
| Leftovers of paper | Wet 15-20%,Dry 60% |
| House garbage | 35%-50% |
| Plastic bags | 50% |
Output product and usage
1. Used as the heating material and sell it to cement factories,
glass factories, ceramic factories, electric power factories, steel
making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant,
color and smell removal system, the final oil can be used in diesel
engines like trucks, tractors, etc.
Slag for construction.
1. Recycled into the furnace to heat reactor instead of
coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.
Main features
A. Safety. We treat safety as the first important thing in
production.
1. Two devices to avoid backfire in production: oil-water separator
and anti-back fire device.
2. Vacuum device makes the reactor work under ordinary pressure or
negative pressure.
3. Temperature monitoring and Pressure gauge to monitor the
pressure. If the pressure goes above a certain level, the bell will
alarm and the safety valve will release the pressure automatically.
B. Environmental protection
1. The flue gas (caused by burning fuel to heat the reactor) will
be purified and cooled by a powerful ceramic packing dust removal
device, then can be released into the air through the chimney.
2. Carbon black will be discharged out in sealed condition to avoid
pollution.
C. Energy saving
1. The flame path is designed as a spiral so that the quantity of
heat can be fully used.
2. The syngas is recycled to heating furnace for burning, thus
saving your heating fuel.
3. The insulation cover is formed by 3 layers: steel plate, rock
wool, and refractory cement. Excellent thermal insulation effect
helps save fuel.
Specification
| Model | HY-05 | HY-08 | HY-10 | HY-15 |
| Raw material | Waste rubbers/tyres/plastic |
| Output product | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Daily Handling capacity | 5 tons | 8 tons | 10 tons | 12 tons |
| Machine dimension(mm) | D2200*L5500 | D2600*L6600 | D2800*L6600 | D2800*L8000 |
| Landing Area | 200m2 | 250m2 | 300m2 | 350m2 |
| Working pressure | Normal pressure |
| Main engine rotating speed | 0.4R /min |
| Power | 15KWH |
| Cooling Mode | Circle Water |
| Heating Mode | Direct |
| Oil Yield | 40%-50% |
| Noise dB (A) | <=85 |
| Working Mode | Batch type |
Our services
1. One-stop solution. We have more than 20 years of rich experience
in manufacturing waste pyrolysis plants. We pay more attention to
customer experience and customer satisfaction. As long as you need
it, we are able to provide you with a better quality complete
production line.
2. We have our own factory and trading company, no middlemen, more
cost-effective, and it is more convenient for you to replace
related parts, as long as there is a problem, we can provide a
solution immediately, product quality is guaranteed.
3. We promise that our plants are efficient and have a long service
life to ensure that you can quickly produce in batches.
4. Delivery time is 15-25 days.
5. We can send engineers on-site to guide installation and train
your workers.
6. One-year warranty, lifelong maintenance of the equipment,
providing professional use guidance services.
FAQ
1. What is the cost of one complete set of waste pyrolysis plants?
The price of the pyrolysis plant depends on the configuration, and
capacity, please contact us to get the latest quotation.
2. What payment methods do you accept?
A: We can accept T/T, L/C, Western Union.
