Processing Plastic Waste To Fuel Waste Plastic Recycling Pyrolysis
Machine With CE
Product description
With the increasing awareness of environmental protection in the
world, the harmless and resourceful disposal of waste tires/plastic
has become an important trend. The waste plastic /tyre recycle to
fuel oil machinery is designed to process the waste into valuable
products -industrial fuel oil, carbon black, and steel wire through
catalytic cracking technology. This green technology has created
good economic and social benefits.
Output product and usage
| Output Products | Application |
Fuel Oil (50%-75%) | 1. Used as the heating material and sell it to cement factories,
glass factories, ceramic factories, electric power factories, steel
making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant,
color and smell removal system, the final oil can be used in diesel
engines like trucks, tractors, etc. |
| Carbon Black (30%-35%) | Slag for construction. |
| Flammable Gas (8%-10%) | 1. Recycled into the furnace to heat reactor instead of
coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch. |
Specification
| Model | HY-05 | HY-08 | HY-10 | HY-15 |
| Raw material | Waste rubbers/tyres/plastic |
| Output product | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Daily Handling capacity | 5 tons | 8 tons | 10 tons | 12 tons |
| Machine dimension(mm) | D2200*L5500 | D2600*L6600 | D2800*L6600 | D2800*L8000 |
| Landing Area | 200m2 | 250m2 | 300m2 | 350m2 |
| Working pressure | Normal pressure |
| Main engine rotating speed | 0.4R /min |
| Power | 15KWH |
| Cooling Mode | Circle Water |
| Heating Mode | Direct |
| Oil Yield | 40%-50% |
| Noise dB (A) | <=85 |
| Working Mode | Batch type |
Main advantages
1. High automation: Loading used tires/plastic into the pyrolysis
reactor with 50ton hydraulic pressure, so the auto feeder can help
you save labor and load more waste raw material, compared with
manual feeding, the automatic feeder is more efficient.
2. 100% safety: The pyrolysis reactor is made of Q245R/Q345R
boilerplate, which is high pressure and high-temperature resistance
that ensure its longer service life. Adding perfect hot seal
technology to ensure operation safely.
3. Environmental friendly: Flue gas is purified by ceramic packing
dedusting device, finally no black smoke emitted.
4. High efficiency discharging device: Discharge carbon black from
pyrolysis reactor after the production is finished in a sealed
condition, no pollution and saves labor and time.
5. Strictly quality control. All of the steel plates are purchased
from China's famous company " Anyang Iron and Steel Co., Ltd ", and
the raw material inspection certificate can be provided to
customers. For each set of machines, we will do ultrasonic
nondestructive testing, and automatic submerged welding technology
to ensure the machine quality.
Oil yield
| Raw materials | Oil ratio |
| PP (Microwave oven food box/yogurt bottles, ect.) | 50%-75% |
| PS(fast food boxes/instant noodle boxes) | 50%-75% |
| PE(plastic film/plastic wrap) | 50%-75% |
| Plastic cable | 80% |
| ABS(engineering plastic) | 40% |
| Leftovers of paper | Wet 15-20%,Dry 60% |
| House garbage | 35%-50% |
| Plastic bags | 50% |
| Submarine cable | 75% |
| Rubber cable | 35% |
| Sole | 30% |
| Small tires | 45%-50% |
| Big tires | 35%-40% |
