    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation

    Ask Lasest Price
    Brand Name : Huayin
    Model Number : HY-10Ton
    Certification : CE ISO
    Price : USD35000-75000 per set
    Payment Terms : L/C, T/T
    Supply Ability : 250 sets per year
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation


    Waste Motor Oil Pyrolysis To Diesel Distillation Plant Used Motor Oil Recycling Machines


    The waste tyre oil recycling to diesel machine with high vacuum molecular distillation technology, it can convert waste pyrolysis oil , waste engine oil into diesel, with features of low cost, high recovery rate, environmentally friendly, and energy-saving.


    Working process of the waste engine oil /pyrolysis oil distillation plant


    1. Pump waste oil into distillation reactor by oil pump.

    2. Heat the reactor, and the liquid oil will slowly become oil gas, oil gas will go through catalytic chamber and condenser, then diesel will be cooled out first by controlling the temperature over 150 Celsius degrees.

    3.The gasoline will be cooled out when the temperature is below 150 Celsius degrees, the rest of the system is the same as pyrolysis system.


    Specification


    Item

    Contents
    Input-Raw MaterialsWaste engine/motor oil/Lubrication oil
    Average out-put oil rate85%-90%
    By-productsDiesel oil, waste gas, slag
    Structure formHorizontal
    Operating pressureConstant pressure
    Heating materialCoal, charcoal, fuel gas, fuel oil
    Model(Diameter*Length)(mm)Reactor sizeCapacity
    D1500*L30003 Ton/Day
    D2000*L50005 Ton/Day
    D2800*L600010 Ton/Day
    Material of reactorQ245R&Q345R boiler plate
    Thickness of reactor16mm, 18mm
    Mode of coolingCirculating water cooling
    Space neededLength: 30m, Width :10 m at most
    Power consumptionAverage 15 KW/h

    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation


    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation



    Main features


    Safety: Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.

    Oil-water separator: Its water sealing design ensures that oil and gas are separated and combustible gas can not return to the reactor.

    Energy-saving:

    The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel.

    The combustible gas that cannot be further cooled down into fuel oil will be recycled to the furnace for heating the reactor, maximizing resource utilization.

    The cooling water adopts a circulating mode, which is pollution-free, no discharging, and recyclable.

    High efficiency discharging: Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution and save labor and time.

    Fast installation: All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality.


    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation

    Huayin Waste Oil Distillation Plant CE , ISO Waste Motor Oil Distillation


    Our service


    Established in 1993, Xinxiang HUAYIN Renewable Energy Equipment Co., Ltd is an environmental protection plant manufacturer integrating product R&D, design, production, marketing, installation and after-sales. HUAYIN Energy enjoys a technical and service team composed of more than 30 experienced engineers and a number of invention patents, CE, SGS, ISO9001 and ISO14001 certifications.
