High-Temperature Small Tyre Pyrolysis Plant Machine Cost With
Profit Analysis
The small capacity tyre pyrolysis plant is used to turning scrap
tires into fuel oil. It is helpful for us to protecting the
environment and it is easy and fast to set up a small pyrolysis
machine. Huayin provides different capacity and designs of
pyrolysis machine for customers and our professional project
consultant will help you choose the most suitable designs according
to customers' processing capacity and budget.
Advantages of Huayin Waste Tyre Pyrolysis Plant
Environmental friendly Huayin waste tyre/plastic pyrolysis plant
No waste water , gas and black smoke discharged out . The water for
condensing system is circular and the water is separated with the
oil gas pipe, so there is no waste water. The syngas that can not
be liquefied will be used for burning as heating fuel . The smoke
produced will be purified by the dedusting device , finally no
black smoke and meets the national emission standard.
High efficiency of Huayin Small Tire Pyrolysis Plant for sale
1. The pyrolysis reactor is manufactured with good material of
Q245R boiler plate which is high pressure and temperature
resistance , 16mm thickness , it is rotating when production ,thus
ensures the raw material can be heated evenly and faster. The
thickened insulation layer minimizes heat loss.
2. Carbon black is conveyed in a sealed condition to achieve
pollution-free and the slag is discharged out automatically through
the screw conveyor.
3. Hydraulic feeder can load more feedstocks since it can compact
feedstocks while feeding. Less feeding time and labour required.
4. Larger condensation area maximizes condensation effect
Profit analysis for waste tyre pyrolysis plant
Remarks :Calculate the profit by processing 10 tons of tires per
day
| Profit Analysis of HY-10T Pyrolysis Plant |
| Raw material | Tyres | 10Ton /Day | $45/Ton |
| Fuel | Pyrolysis oil | 200kg/Day | |
| Electricity | 50KW/H | 18 Hours | $0.14/KWH |
| Labour | 4 persons | 1 day | $50/person/day |
| Pyrolysis oil | 45% oil yield | 4.5Ton | $410/Ton |
| Carbon black | 30% yield | 3Ton | $50/Ton |
| Steel wire | 15% yield | 1.5Ton | $150/Ton |
| Daily Input | | | |
| Items | Consumption | Unit Price | Total |
| Tyre | 10Ton | $50 | $500 |
| Pyrolysis oil | 200KG | $0 | $0 |
| Electricity | 300KW | $0.14 | $42 |
| Labour | 4 persons | $50 | $200 |
| Total | | | $742 |
| Daily output | | | |
| Items | Quantities | Unit price | Total |
| Pyrolysis oil | 4.5Ton | $410 | $1845 |
| Carbon black | 3Ton | $50 | $150 |
| Steel Wire | 1.5Ton | $150/Ton | $225 |
| Total | | | $2220 |
| Daily Net profits | $1478 | | |
| Month Profits (25 working day) | $36950 | | |
| Annual profit (10 months) | $369500 | | |
