Tyre To Oil Pyrolysis Plant Waste Plastic To Petrol Diesel Fuel
Pyrolysis Machine
Product description
With the rising public awareness for environmental protection,
Waste tire/plastic recycling has attracted more and more attention
all over the world. Huayin pyrolysis technology can convert waste
tires, rubber, and plastic scrap into fuel oil, carbon black, steel
wire and combustible gas. The plant has the advantages of
environmental friendly, energy-saving, high oil yield and quality,
and longer service life.
Specification
| Item | Content |
| Raw materials | Waste tyre/rubber |
| Output | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch |
| HY2200*5500 | 5 T/batch |
| HY2200*7500 | 7 T/batch |
| HY2600*6600 | 8 T/batch |
| HY2800*6000 | 9 T/batch |
| HY2800*6600 | 10 T/batch |
| HY2800*8000 | 15 T/batch |
| Remarks | Support customization |
| Reactor material and thickness | Q345R/Q245R/310S (Boiler plate/stainless steel) 16mm/18mm |
| Land area | 300-400㎡ (L30-40m*W10m) |
| Number of workers | 3-4 |
| Oil density and calorific value | 0.89g/cm³&44.30KJ/KG |
| Processing time and power | 10-24 hours. Averagely 15KW/h |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents |
Output product and application
| Output Products | Application |
| Fuel Oil (40%-55%) | 1. Used as the heating material and sell it to cement factories,
glass factories, ceramic factories, electric power factories, steel
making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant,
color, and smell removal system, the final oil can be used in
trucks, tractors, etc. |
| Carbon Black (30%-35%) | 1. Make it to pellet or briquette as heating material. |
| Steel Wire (10%-15%) | Sell to iron and steel factory directly. |
| Flammable Gas (8%-10%) | 1. Recycled into the furnace to heat reactor instead of heating
material. 2. Storage the excess gas to restart the next batch. |
Operation process of pyrolysis plant
1. Loading the waste material into the pyrolysis reactor manually
or with auto feeder.
2. Heating the pyrolysis reactor and producing oil.
3. The exhaust gas which can not be cooled to liquid oil will be
recycled to heat the reactor. Smoke will be purified through strong
and powerful dust removal device.
4. Cool the pyrolysis reactor after oil production is finished.
5. Discharging carbon black and steel wire.
Main features
A. The high degree of automation
1. In manufacturing we use auto-cutting machines, auto welding
machines, and auto rolling machines so that both the quality and
appearance of our products can be guaranteed.
2. In production, we use auto-feeder to feed raw materials into the pyrolysis reactor. By auto-feeder it needs few workers and less
time to feed. And because of 50-ton hydraulic pressure, it can feed
more tires than manually feeding.
B. Long service life
1. The material of the reactor is Q345R/Q245R boiler plate with
16/18mm thickness which is produced by a Chinese well-known
enterprise. The head of the reactor and accessories are using
one-piece molding shell cover rather than a welded plate.
2. The rollers are engineered underfeeding port and oil outlet port
which are external to the heating area to bring perfect rotating
balance and longer service life.
C. Environmental protection
1. The flue gas (caused by burning fuel to heat the reactor) will
be purified and cooled by a powerful ceramic packing dust removal
device, then can be released into the air through the chimney.
2. Carbon black will be discharged out in sealed condition to avoid
pollution.
After-sales Service
1. Based on customers’ requests and budgets, we help you make the
most economic solutions.
2. Providing a Turnkey project.
3. Engineers are available to go overseas for plant installation,
test the machine, and train workers.
4. One year warranty for the main reactor of pyrolysis machines and
lifetime maintenance for complete machines.
